Fireye 1044-40, EP380 Programmer Module (b) | Burner Control |
1044-40, EP380 Drive Specifications: Voltage, Current & Interface
Motor & System Compatibility for Fireye 1044-40, EP380
1 / 3
+3
+3
1 / 3
| Description | Details |
|---|---|
| Available Quantity | 1 |
| Model | 1044-40, EP380 |
| Condition | New |
| Manufacturer | Fireye |
| Asset Number | KSC1290 / 1277 |
| Guarantee or ASIS | 1. HIGH CONFIDENCE ITEM: We will offer a 100% 14 Day money back less S&H. |
| Inspections - Yellow Tag | 1. New in Box |
| Packaging Cost | 1.6 6x10 CH $3.00 |
Available Qty: 1
Free Shipping
$349.50
Basic Information
Asset #
KSC1290 / 1277
Available Quantity
1
Inspections - Yellow Tag
1. New in Box
Condition
New
Guarantee or ASIS
1. HIGH CONFIDENCE ITEM: We will offer a 100% 14 Day money back less S&H.
Item Description
N/A
Factory Information
- Manufacturer: Fireye
- Model: EP380 (part marking 1044-40)
- Type: Programmer module for the Fireye Flame-Monitor burner management control system
- Host Control: Fireye FLAME-MONITOR chassis, P/N E110
- Pre-ignition Air Change Time: selectable, 30 second minimum; extended timing set by DIP switches 3, 4 and 5
- Trial For Ignition (TFI): selectable
- Recycle: selectable recycle / non-recycle operation
- Modulation: none on this model
- Configuration: six DIP switches on the side of the programmer set the operational characteristics
- Safety Response: de-energizes all fuel valve circuits within 4 seconds maximum following a flame failure, or at the end of the pilot trial for ignition if no flame is detected
- Functions Provided: start-up programming, safe-start check and flame monitoring supervision
- Spec Basis: Fireye published bulletin EP-3801, Flame-Monitor Programmer Modules EP380 / EP381 / EP382 / EP383 / EP390
Specifications
Manufacturer
Fireye
Model
1044-40, EP380
Serial
55-5703-3
Year
N/A
HP / AMP / KW / KVA
N/A
Amps
N/A
Length (Inches)
6
Width (Inches)
6
Height (Inches)
1
Phase
N/A
Estimated Packaging Weight
0
Estimated Total Weight
0.61875
Asset Number
KSC1290 / 1277
Packaging fees
Packaging Cost
1.6 6x10 CH $3.00
