SICK IME08-1B5PSZW2S (1040840)
IME08-1B5PSZW2S Sensor Specifications: Range, Output & Supply Voltage
Process & Machine Applications for SICK IME08-1B5PSZW2S
1 / 4
+4
+4
1 / 4
| Description | Details |
|---|---|
| Available Quantity | 2 |
| Model | IME08-1B5PSZW2S |
| Condition | New |
| Manufacturer | SICK |
| Asset Number | KSC1290 / 731 |
| Guarantee or ASIS | 2. WE GUARANTY OUR WORKMANSHIP & OUR WORD ONLY: 14 Day return |
| Inspections - Yellow Tag | 1.1 Appears Unused no box |
| Packaging Cost | 1.6 6x10 CH $3.00 |
Available Qty: 2
$29.95
Basic Information
Asset #
KSC1290 / 731
Available Quantity
2
Inspections - Yellow Tag
1.1 Appears Unused no box
Condition
New
Guarantee or ASIS
2. WE GUARANTY OUR WORKMANSHIP & OUR WORD ONLY: 14 Day return
Item Description
N/A
Factory Information
- Manufacturer: SICK AG
- Model: IME08-1B5PSZW2S (SICK part number 1040840)
- Type: Inductive proximity sensor, IME series
- Barrel: M8 x 1 fine thread, 8 mm diameter
- Mounting: Flush / embeddable
- Sensing Range: 1.5 mm
- Supply Voltage: 10-30 V DC
- Output: PNP normally open (NO), DC 3-wire
- Output Current: 200 mA
- Switching Frequency: 4,000 Hz
- Output Voltage Loss: ≤ 2 V
- Housing: Nickel-plated brass
- Enclosure Rating: IP 67
- Connection: 2 m cable, 3-wire
- Approvals: cULus Listed
- Spec Basis: SICK AG published IME series data sheet
Specifications
Manufacturer
SICK
Model
IME08-1B5PSZW2S
Serial
N/A
Year
N/A
HP / AMP / KW / KVA
N/A
Amps
N/A
Length (Inches)
5
Width (Inches)
5
Height (Inches)
1
Phase
N/A
Estimated Packaging Weight
2
Estimated Total Weight
2.008125
Asset Number
KSC1290 / 731
Packaging fees
Packaging Cost
1.6 6x10 CH $3.00
