Ferraz Shawmut OTM 30, Fast-Acting Midget Fuse, 30A, 250V
OTM 30 Fuse Specifications: Amps, Voltage & Class
Replacement & Interchange for Ferraz Shawmut OTM 30
1 / 3
+3
+3
1 / 3
| Description | Details |
|---|---|
| Available Quantity | 6 |
| Model | OTM 30 |
| Condition | New |
| Manufacturer | Ferraz Shawmut |
| Asset Number | KSC1230 / 1137 |
| Guarantee or ASIS | 2. WE GUARANTY OUR WORKMANSHIP & OUR WORD ONLY: 14 Day return |
| Inspections - Yellow Tag | 1.1 Appears Unused no box |
| Packaging Cost | 1.6 6x10 CH $3.00 |
Available Qty: 6
$4.95
Basic Information
Asset #
KSC1230 / 1137
Available Quantity
6
Inspections - Yellow Tag
1.1 Appears Unused no box
Condition
New
Guarantee or ASIS
2. WE GUARANTY OUR WORKMANSHIP & OUR WORD ONLY: 14 Day return
Item Description
N/A
Factory Information
- Manufacturer: Ferraz Shawmut (now Mersen)
- Model: OTM30
- Type: One-time, fast-acting midget fuse
- Class: Midget, supplemental protection
- Current Rating: 30 A
- Voltage Rating: 250 VAC
- Interrupting Rating: 10 kA
- Terminal Type: Ferrule
- Body Size: 0.41 in (13/32 in) diameter x 1.5 in length (10.41 x 38.1 mm)
- Approvals: UL 248-14, CSA C22.2, RoHS
- Application: General-purpose 250 VAC lighting, heating and control circuits where time delay is not required. Not rated for branch circuit protection.
- Spec Basis: Mersen / Ferraz Shawmut published OTM series catalogue data
Specifications
Manufacturer
Ferraz Shawmut
Model
OTM 30
Serial
N/A
Year
N/A
HP / AMP / KW / KVA
N/A
Amps
30
Length (Inches)
2
Width (Inches)
1
Height (Inches)
1
Phase
1
Estimated Packaging Weight
0.2
Estimated Total Weight
1.2
Asset Number
KSC1230 / 1137
Packaging fees
Packaging Cost
1.6 6x10 CH $3.00
