Igus CF5.03.18 Chainflex Control Cable 18 x 18 AWG (18 x 0,34)
18 x 18 AWG Specification and Benefits
Why Choose Igus Chainflex Control Cables?
1 / 5
+5
+5
1 / 5
| Description | Details |
|---|---|
| Available Quantity | 2 |
| Model | CF5.03.18 |
| Condition | New |
| Manufacturer | Igus |
| Asset Number | KSC1290 / 2188 |
| Guarantee or ASIS | 2. WE GUARANTY OUR WORKMANSHIP & OUR WORD ONLY: 14 Day return |
| Inspections - Yellow Tag | 1.1 Appears Unused no box |
| Packaging Cost | 1.6 6x10 CH $3.00 |
Available Qty: 2
Free Shipping
$39.95
Basic Information
Asset #
KSC1290 / 2188
Available Quantity
2
Inspections - Yellow Tag
1.1 Appears Unused no box
Condition
New
Guarantee or ASIS
2. WE GUARANTY OUR WORKMANSHIP & OUR WORD ONLY: 14 Day return
Item Description
Unused New Surplus. Ships from TX, USA. Free same day shipping
Factory Information
- Manufacturer: igus
- Model: CF5.03.18 (also listed as CF5-03-18)
- Series: chainflex CF5 control cable
- Number of Conductors: 18
- Conductor Cross-Section: 0.34 mm2 per conductor (22 AWG)
- Shielding: Unshielded
- Voltage Rating: 300/500 V (IEC); 600 V (UL/AWM Style 2570)
- Jacket Material: PVC, oil-resistant and flame-retardant; green
- Outer Diameter: 11.99 mm (0.472 in)
- Conductor Material: Bare copper, fine-wire stranded (Class 5)
- Temperature Range (moving): +5 degrees C to +70 degrees C
- Min. Bend Radius (moving): 4 x outer diameter
- Certifications: UL, CE, RoHS II, EAC; flame-retardant per IEC 60332-1-2, VW-1, FT-1
- Application: Continuous flexing in cable carrier systems (e-chains); machine tools, automation
Specifications
Manufacturer
Igus
Model
CF5.03.18
Serial
N/A
Year
N/A
HP / AMP / KW / KVA
N/A
Amps
N/A
Length (Inches)
13
Width (Inches)
13
Height (Inches)
2
Phase
1
Estimated Packaging Weight
N/A
Estimated Total Weight
2.5375
Asset Number
KSC1290 / 2188
Packaging fees
Packaging Cost
1.6 6x10 CH $3.00
Payment Details
Appraised Value
$39.95
Payment MethodsPayment Types Accepted : N/A
