Danfoss Inverter Scroll Compressor HRH051U2LP6 121L1466 (4.25 Tons 51K BTU)
$895.00
Save for later
Basic Information
Asset # : KSC1230 / 22
Available Qty: 19
Inspections - Yellow Tag : 1. New in Box
Condition : New
Guarantee or ASIS : 1. HIGH CONFIDENCE ITEM: We will offer a 100% 14 Day money back less S&H.
Payment Details
Appraised Value: $895.00
Payment Types Accepted : Visa , Mastercard , Check (14 Day Hold Before Release) , Cash
Shipping Options
Packaging Cost : 1.2 Cardboard $15
ITEM DESCRIPTION
This Danfoss Inverter Scroll Compressor HRH051U2LP6 121L1466 is an exceptional product that brings efficiency and durability to your heating, ventilation, and air conditioning (HVAC) system. With a cooling capacity of 4.25 Tons or 51K BTU, it's designed to comfortably regulate large spaces, easing you through intense heat waves. As user-friendly as it's effective, this model employs the highly reputed Inverter technology, allowing precise control of temperature all while conserving energy. Its scroll compressor type is recognized for its quiet and smooth operation, longevity, and fewer moving parts. The Danfoss brand itself stands as a testament to quality and robustness. This compressor has been opted for numerous commercial applications due to its unmatched reliability. Incorporating this Danfoss Inverter Scroll Compressor into your HVAC system isn't just an upgrade, it's a testament to your decision to opt for superior performance, energy efficiency and peace of mind. Remember, by making smart investments today, you are setting up yourself for a comfortable and cost-effective future!
Read More ▼
INSPECTION REPORT
Specifications
DESCRIPTION
DETAILS
Manufacturer :
Danfoss
Serial #:
MF2505292246
HP / AMP / KW / KVA :
60Hz
Length (Inches):
10
Estimated Packaging Weight:
N/A
Estimated Total Weight:
83
DESCRIPTION
DETAILS
Model :
HRH051U2LP6
Year :
2020
Amps :
N/A
Phase :
3
Width (Inches):
10
Height (Inches):
16
Factory Information
Product details
| Gross weight | 38 Kilogram |
| Net weight | 28 Kilogram |
| Volume | 0.1 Cubic meter |
| EAN | 5702424206116 |
| Approval | CE UL UKCA |
| Brand technique | Scroll compressor |
| Capacity control | Fixed speed |
| China RoHS compliance | Out of scope |
| Colour | Blue |
| Compressor power supply [V] | 200-220/3/50 208-230/3/60 |
| Configuration code | Single |
| Connection type | Brazed |
| Description | HRH051U2 |
| Diameter [mm] | 184 mm |
| Discharge connection height [mm] | 422 mm |
| Discharge connection pipe size [in] | 1/2 in |
| Discharge connection size [in] | 1/2 in |
| Drawing number | 0XR6002B-2 |
| Economizer | No |
| EU RoHS compliance | Yes with exemptions |
| EU RoHS exemption clause | 6(a), 6(a)-I, 7(a), 7(c)-I, 8(b), 9(b) |
| Family | HRH |
| Fitting standard | ODF |
| Frequency [Hz] | 50/60 |
| Gauge port HP | None |
| Gauge port LP | None |
| Gaz equalization | None |
| Glass mounting | None |
| High value of nominal voltage at 50Hz [V] | 220 V |
| High value of nominal voltage at 60Hz [V] | 230 V |
| High value of voltage range at 50Hz [V] | 242 V |
| High value of voltage range at 60Hz [V] | 253 V |
| In scope of WEEE and contain batteries | No |
| IP protection class | IP22 |
| Length [mm] | 239 mm |
| Low value of nominal voltage at 50Hz [V] | 200 V |
| Low value of nominal voltage at 60Hz [V] | 208 V |
| Low value of voltage range at 50Hz [V] | 180 V |
| Low value of voltage range at 60Hz [V] | 187 V |
| LRA | 120 A |
| Max pressure (PS) - high side | 46.1 bar |
| Max pressure (PS) - low side | 31.1 bar |
| MCC | 27.5 A |
| Model number | HRH051U2LP6 |
| Motor protection | Internal overload protector |
| Network power supply [V/Ph/Hz] | 200-230/3/50 208-230/3/60 |
| Oil charge [L] | 1.57 L |
| Oil drain | None |
| Oil equalization | None |
| Oil reference | 320HV |
| Oil type | PVE |
| Packing format | Single pack |
| Packing quantity | 1 |
| Phase | 3 |
| Power connections | Spade |
| Product group | Hermetic compressors |
| Product Name Description | Scroll compressor HRH |
| Refrigerant charge [kg] [Max] | 5.44 kg |
| Refrigerants | R410A |
| RLA | 17.6 A |
| Rotational speed at 50Hz [rpm] | 2900 rpm |
| Rotational speed at 60Hz [rpm] | 3500 rpm |
| Segment usage | Air conditioning |
| Suction connection height [mm] | 280 mm |
| Suction connection material | - |
| Suction connection pipe size [in] | 7/8 in |
| Suction connection size [in] | 7/8 in |
| Swept volume [cm3] | 49.32 cm³ |
| Technology | Scroll |
| Total height [mm] | 455 mm |
| Type | HRH051 |
| UK RoHS compliance | Out of scope |
| Viscosity [cP] | 68 cP |
| Width [mm] | 239 mm |
| Winding resistance 1-2 [Ohm] | 0.6 |
| Winding resistance 1-3 [Ohm] | 0.6 |
| Winding resistance 2-3 [Ohm] | 0.61 |
