The HRP034T1LP6 is a hermetic scroll compressor, the component that circulates and pressurizes refrigerant in an air conditioning or heat pump system. It uses scroll compression: two interleaved spiral elements, one fixed and one orbiting, trap refrigerant gas at the outer edge and squeeze it inward into progressively smaller pockets, raising its pressure and temperature before discharge to the condenser. The motor and scroll set are sealed together inside a welded steel shell (hermetic), so the unit is not internally serviceable and is replaced as a whole. It is fixed-speed, running at one speed and cycling on and off to match cooling load.

This model is built for R407C refrigerant with PVE lubricant and produces about 2.8 tons of cooling (roughly 33,000 BTU/hr). It runs on 208-230 V single-phase, 60 Hz power, placing it in residential and light commercial equipment such as split-system condensing units, small packaged units, and heat pumps where three-phase power is not available. The model code decodes as H (air conditioning duty), R (residential-platform scroll), P (R407C, PVE oil), 034 (nominal capacity in thousands of BTU/hr), T (optimized for 45/130°F conditions), 1 (208-230 V single-phase), L (internal motor overload protection), P6 (brazed connections, spade terminals).
