Edwards 600GA TRANS 10TR NW-16 (Code # W60321811) Barocel Pressure Sensor 10 Torr Range
Accurate Pressure Measurement with 10 Torr Range
Key Features of the Edwards 600GA Barocel Pressure Sensor
1 / 4
+4
+4
1 / 4
| Description | Details |
|---|---|
| Available Quantity | 2 |
| Model | 600GA TRANS 10TR NW-16 |
| Condition | New |
| Manufacturer | Edwards Vacuum Products |
| Asset Number | KSC1290 / 589 |
| Guarantee or ASIS | 1. HIGH CONFIDENCE ITEM: We will offer a 100% 14 Day money back less S&H. |
| Inspections - Yellow Tag | 1. New in Box |
| Packaging Cost | 1.6 6x10 CH $3.00 |
Available Qty: 2
Free Shipping
$586.50
Basic Information
Asset #
KSC1290 / 589
Available Quantity
2
Inspections - Yellow Tag
1. New in Box
Condition
New
Guarantee or ASIS
1. HIGH CONFIDENCE ITEM: We will offer a 100% 14 Day money back less S&H.
Item Description
Suprlus New Stock. Ships from TX, USA. Free same day Shipping
Factory Information
- Manufacturer: Edwards Vacuum (formerly BOC Edwards)
- Model: Barocel 600GA TRANS 10TR NW-16 (Code W60321811)
- Type: Capacitance manometer (direct pressure sensor)
- Pressure Range: 0 to 10 Torr (full scale)
- Vacuum Connection: NW-16 (KF-16) ISO flanged fitting
- Output Signal: 0 to 10 V DC, linear with pressure
- Supply Voltage: 13.5 to 36 V DC, 0.4 W
- Accuracy: 0.15% of reading
- Resolution: better than 1 in 10,000 of full scale
- Temperature Effect on Zero: less than 0.005% full scale per deg C
- Temperature Effect on Sensitivity: less than 0.02% reading per deg C
- Overpressure (no damage): 1.25 times full scale or 2.4 bar, whichever is greater
- Operating Temperature: 0 to 65 deg C
- Response Time Constant: 8 ms
- Internal Volume: 8.3 cm3
- Wetted Materials: Inconel and Monel diaphragm and body
- Reference: Integral all-welded vacuum reference with gettering material for long-term zero stability
Specifications
Manufacturer
Edwards Vacuum Products
Model
600GA TRANS 10TR NW-16
Serial
001014530
Year
10/18/2000
HP / AMP / KW / KVA
N/A
Amps
N/A
Length (Inches)
7
Width (Inches)
14
Height (Inches)
7
Phase
N/A
Estimated Packaging Weight
N/A
Estimated Total Weight
2.9375
Asset Number
KSC1290 / 589
Packaging fees
Packaging Cost
1.6 6x10 CH $3.00
