AW-Lake JVA-60 Positive Displacement Spur Gear Flow Meter Body, 6000 PSI Max
JVA-60 Flow Meter Specifications: Range, Size & Output
Process Fitment for AW-Lake JVA-60
1 / 10
+10
+10
1 / 10
| Description | Details |
|---|---|
| Available Quantity | 1 |
| Model | JVA-60 |
| Condition | Used |
| Manufacturer | AW-Lake |
| Asset Number | KSC1290 / 244 |
| Guarantee or ASIS | 2. WE GUARANTY OUR WORKMANSHIP & OUR WORD ONLY: 14 Day return |
| Inspections - Yellow Tag | 5. Used: Unit looks good to us |
| Packaging Cost | 1.6 6x10 CH $3.00 |
Available Qty: 1
$2,140.00
Basic Information
Asset #
KSC1290 / 244
Available Quantity
1
Inspections - Yellow Tag
5. Used: Unit looks good to us
Condition
Used
Guarantee or ASIS
2. WE GUARANTY OUR WORKMANSHIP & OUR WORD ONLY: 14 Day return
Item Description
N/A
Factory Information
- Manufacturer: AW-Lake Company (Oak Creek, WI)
- Model: JVA-60 (JV-BB series, size 60, aluminium body)
- Type: Positive displacement spur gear flow meter body
- Flow Range: 0.1 to 20.0 GPM (0.5 to 75.7 LPM; 144 to 28,800 gal/day)
- Maximum Operating Pressure: 6,000 PSI (420 bar)
- Port Size: 3/4 in NPT standard (BSPP and bottom manifold mount optional)
- Body Material: JVA = 7075 aluminium
- Gears and Bearings: Stainless steel (DIN 1.4122)
- Shaft: 402 stainless steel
- O-Ring: FKM, FFKM or PTFE
- Resolution: 3,600 impulses/gal (0.95 impulses/cc) with dual pickup sensor
- Accuracy: ±0.5% of measured value over the full range with 30 cP fluid
- Repeatability: ±0.1%
- Turndown: Up to 150:1
- Temperature Range: -40 °F to +356 °F (-40 °C to +180 °C)
- Required Filtration: 30 micron
- Dimensions: A 5.0 in, B 4.9 in, C 0.75 in, D 2.4 in, H 4.3 in; mounting holes M8 x 1.25 x 16 mm
- Weight: 9.1 lb (aluminium body)
- Service: Lubricating and non-abrasive fluids of low to medium viscosity
- Spec Basis: AW-Lake JV-BB Positive Displacement Gear Flow Meter data sheet, Doc ID JVBBDS21 REV 02.26, meter size 60 row
Specifications
Manufacturer
AW-Lake
Model
JVA-60
Serial
55551033
Year
N/A
HP / AMP / KW / KVA
N/A
Amps
N/A
Length (Inches)
6
Width (Inches)
6
Height (Inches)
4
Phase
N/A
Estimated Packaging Weight
2
Estimated Total Weight
32
Asset Number
KSC1290 / 244
Packaging fees
Packaging Cost
1.6 6x10 CH $3.00
