Danfoss Scroll Compressor 2.7 Ton 32,000 BTU HRH032U1LP6 208-230V 1 Phase R410A
Danfoss Scroll Compressor 2.7 Ton 32,000 BTU HRH032U1LP6 208-230V 1 Phase R410A
Danfoss Scroll Compressor 2.7 Ton 32,000 BTU HRH032U1LP6 208-230V 1 Phase R410A
Danfoss Scroll Compressor 2.7 Ton 32,000 BTU HRH032U1LP6 208-230V 1 Phase R410A
| Description | Details |
|---|---|
| Available Quantity | 4 |
| Model | HRH032U1LP6 |
| Condition | New |
| Manufacturer | Danfoss |
| Asset Number | KSC1230 / 1110 |
| Guarantee or ASIS | 1. HIGH CONFIDENCE ITEM: We will offer a 100% 14 Day money back less S&H. |
| Inspections - Yellow Tag | 1. New in Box |
| Packaging Cost | 1.1 Cardboard $10 |
$483.95
Basic Information
Asset #
KSC1230 / 1110
Available Quantity
4
Inspections - Yellow Tag
1. New in Box
Condition
New
Guarantee or ASIS
1. HIGH CONFIDENCE ITEM: We will offer a 100% 14 Day money back less S&H.
Item Description
The HRH032U1LP6 is a hermetic, fixed-speed scroll compressor for air conditioning. A fixed and an orbiting spiral compress refrigerant inside a sealed welded shell; it runs at one speed and cycles on and off to regulate capacity. Mechanically it is the same compressor as the three-phase HRH032; only the motor winding and electrical configuration differ.
This model is built for R410A refrigerant with PVE lubricant and rated at about 2.7 tons (31,990 BTU/hr at 60 Hz), the smallest frame in this group. It runs on 208-230 V single-phase, 60 Hz power and is used in smaller residential and light commercial condensing units and heat pumps on single-phase supply. The code decodes as H (air conditioning), R (residential-platform scroll), H (R410A, PVE oil), 032 (capacity class), U (optimized for 45/100°F), 1 (208-230 V single-phase), L (internal protection), P6 (brazed, spade terminals).
Factory Information
| Specification | Value |
|---|---|
| Manufacturer | Danfoss (Performer H-series) |
| Model | HRH032U1LP6 |
| Ordering code | 121L1138 (industrial pack) |
| Compressor type | Hermetic scroll, fixed speed |
| Refrigerant | R410A |
| Lubricant | PVE |
| Nominal cooling capacity | 2.7 Ton (31,990 BTU/hr at 60 Hz, ARI) |
| Power supply | 208-230 V / 1-phase / 60 Hz |
| Swept volume | 30.6 cm3 |
| Oil charge | 1.06 L (36 oz) |
| Motor protection | Internal line-break protector |
| Connection type | Brazed, spade terminals |
| IP rating (terminal box) | IP22 |
| Approvals | UL, CE |
| Net weight | 32.2 kg (71 lb) |
Specifications
Danfoss
HRH032U1LP6
2505058156
2021
50/60Hz
N/A
12
12
18
1
N/A
71
KSC1230 / 1110
Packaging fees
1.1 Cardboard $10
Payment Details
$483.95
Payment MethodsPayment Types Accepted : N/A
